ബാറ്ററി പാക്ക് | സവിശേഷത | പരാമർശിക്കുക | |
Model No. | AIN36100 | / | |
ബാറ്ററി തരം | 36V LiFEPO4 battery | / | |
നാമമാത്ര വോൾട്ടേജ് | 36V / 38.4Volt | customizable Voltage | |
Charge Cut-off (BMS protection) | 45volt±0.35volt | / | |
Discharge Cut-off (BMS protection) | 27.6volt±1.2volt | / | |
Standard / Nominal Capacity | 105Ah | customizable | |
Approx. Weight | 29kg | / | |
Pack Type | 12S1P | customizable | |
Reserve Minutes @0.2C 25℃ / | 300minutes | / | |
പ്രവർത്തിക്കുന്ന വോൾട്ടേജ് | 27.6volt~43.8volt | customizable | |
പീക്ക് ഡിസ്ചാർജ് കറന്റ് | 300A±25A within 5second | customizable | |
ഇംപെഡൻസ് | ≤10mΩ | / | |
Built-in Cell Model | Prismatic @ 100Ah/50Ah/300Ah | customizable | |
ചാർജ്ജ് താപനില | 32(℉)~122(℉) | / | |
ഡിസ്ചാർജ് താപനില | -4(℉)~140(℉) | / | |
സൈക്കിൾ ജീവിതം | 4000cycle (80%DOD) | / | |
Max Cont. discharge current | 100 എ | customizable | |
ചാർജ് രീതി | സിസി / സിവി | customizable | |
Built-in BMS system | അതെ | / | |
BMS Protection Type | Over-Charge, Over-Dishcarge, Over-Voltage, Over-Current, Short-Circuit, Auto-reset | / | |
BMS Balance Type | Active Auto-Balancing | / | |
അളവുകൾ | 53*22*17cm | customizable | |
Connection Type | Modular Pack welding or laser spot welding | / | |
ബി.എം.എസ് | Balanced Current ( BMS ) | 20~30mA | / |
Balanced voltage | 3.6volt | / | |
Over Charge Protection | 3.75±0.0.3v / cell | / | |
Release Voltage for overcharge | 3.60±0.05v | / | |
Rated Charge Current Protection | 100 എ | customizable | |
Detection delay (over-Charge) | 1000mS | / | |
Short circuit trigger condition | external load short circuit | / | |
Detection delay (short-circuit) | 200uS | / | |
Over-Discharge Cut-Off Voltage | 2.1V±0.1V / cell | / | |
Over-Discharge Release Voltage | 2.3V±0.1v | / | |
Discharge protection current | 300 (10mS) | / | |
Rated Discharge Current | ≤100A | customizable | |
Release condition (short circuit & over discharge) | Disconnect Load & Charge Activation | / | |
Detection delay (over-discharge ) | 1000mS | / | |
Communication interface | Bluehost / RS485 / RS232 GPS protocol port for Choice | customizable | |
Temperature control protection | Discharge protection: 167 (℉)±40 (℉) | / | |
പ്രവർത്തന താപനില | -4(℉) ~ 176(℉) | / | |
Over Heat Temperature Protection(Charge&Dishcarge) | 167(℉)±41(℉) | / | |
High temperature release value(Charge&Dishcarge) | 127.4(℉) | / | |
LED ഇൻഡിക്കേറ്റർ | Display Value | Voltage / Capacity percent / Work Temperature | customizable |
സർട്ടിഫിക്കറ്റ് | CE, MSDS, CB-SG, UN38, UL1642 | customizable | |
Outside Battery Box | Outside Protection Box | Stainless steel outer box | Available ABS BOX Series |
IP Level | IP65 | customizable | |
Aging | Lead time | 5-15days normally | rely on the order quantity |
Shipment Time | 7-12days by express, 15~35days by Air, sea and rail transportation | / | |
Quality Assurance | വാറന്റി | 3 year / 36 months | / |
Product advantages

അപ്ലിക്കേഷനുകൾ
1) Energy Storage: UPS, backup, power station.
2) EV: Golf trolleys, Electric scooters.
3) Solar Energy Storage Systems, Wind Energy Storage,Solar/Storage Home System, Solar Street Light.
4) ടെലികമ്മ്യൂണിക്കേഷൻ ബേസ് സ്റ്റേഷനുകൾ.
5) Marine Boat.
6) UPS (Uninterrupted Power Supply).
7) General Energy Storage (Such as Back-up Power, Miner's lamp, portable power supply, digital products, etc.)
ബന്ധപ്പെട്ട LFP ബാറ്ററികൾ
ഞങ്ങളുടെ ഫാക്ടറി
പാക്കിംഗും ഷിപ്പിംഗും
A1: Yes, we are the original factory, specializing in NiMH battery and lithium battery for more than 10 years.
Q2: എനിക്ക് ഒരു സാമ്പിൾ ഓർഡർ നൽകാനാകുമോ?
A2: അതെ, ഗുണനിലവാരം പരിശോധിക്കുന്നതിനും പരിശോധിക്കുന്നതിനുമുള്ള സാമ്പിൾ ഓർഡർ ഞങ്ങൾ സ്വീകരിക്കുന്നു, ആവശ്യാനുസരണം ബാറ്ററി നിർമ്മിക്കാൻ കഴിയും.
Q3: നിങ്ങൾക്ക് MOQ ഉണ്ടോ?
A3: പരിമിതമല്ല, എന്നാൽ നിങ്ങൾ കൂടുതൽ ഓർഡർ ചെയ്യുമ്പോൾ മികച്ച വില നിങ്ങൾക്ക് ലഭിക്കും.
Q4: നിങ്ങളുടെ ഡെലിവറി തീയതി എന്താണ്?
A4: കൃത്യമായ ഓർഡർ അളവിന് വിധേയമായി പേയ്മെന്റ് സ്ഥിരീകരിച്ചതിന് ശേഷം 3-5 ആഴ്ചകൾ.
Q5: ഏത് ഷിപ്പിംഗ് രീതിയാണ് നിങ്ങൾ സാധാരണയായി സ്വീകരിക്കുന്നത്?
A5: സാധാരണയായി, എക്സ്പ്രസ് അല്ലെങ്കിൽ എയർ വഴി ചെറിയ വോളിയം. കടൽ വഴിയുള്ള ബൾക്ക് ഓർഡർ അളവ്.
Q6: നിങ്ങൾ ഏത് തരം പാക്കിംഗ് നൽകുന്നു?
A6: Standard export carton or wooden case according to battery size and weight, the package will be strong enough for long-distance transport.
നിങ്ങളുമായി ദീർഘകാല സഹകരണ ബന്ധം സ്ഥാപിക്കാൻ ഞങ്ങൾ ആത്മാർത്ഥമായി ആഗ്രഹിക്കുന്നു, നിങ്ങൾക്ക് എന്തെങ്കിലും ചോദ്യങ്ങളുണ്ടെങ്കിൽ, ദയവായി ഞങ്ങളെ ബന്ധപ്പെടാൻ മടിക്കരുത്!
